Portable Explosion-proof LED Work Light

Item NO.: CES-EX-FL-4831

It is suitable for all kinds of construction, rescue missions, it can also be used by rescue workers as warning signs, or for position signaling and communication signaling.

hazardous_area_lighting
hazardous_area_lighting
hazardous_area_lighting



  • Superb Energy Efficiency: Adopting high-energy memoryless lithium battery, which has the advantages of large capacity, long service life, charging flexibility, low self-discharge rate, and is economically and environmentally friendly.
  • Adaptability: It adopts high intensity spotlight, ultra-high brightness LED light source, which can send warning signals or indicate locations in two opposite directions at the same time. The luminous surface is 110mm extra large. The maximum visible distance in one direction is up to 1500m. The luminous area radiates light evenly, provides good visibility under rainy and foggy conditions.
  • Waterproofing and fall resistance: The casing is made of high hardness tempered glass lens and high-strength alloy. It is not easy to scratch and has high wear resistance. It can withstand strong collision and impact, has good sealing and strong waterproof ability, and can work normally in various outdoor harsh environments and climate conditions.
  • Intelligent control: There are two working modes: strobe and continuous light which can be switched at will via an intelligent switch.
  • Light and durable: It is portable, and can be attached to the surface of steel parts via magnetic attraction or hung on other objects. It can be extend or retracted on demand. Convenient to carry and easy to operate.
  • Other configurations: Red, yellow, green light sources can be selected on according to actual needs.

Battery

  • Rated voltage: DC 3.7 V
  • Rated capacity: 2 Ah
  • Battery capacity 1500mAh
  • Battery battery life: (Rechargeable times)≥1000
  • Charging time: ≤ 6 hours
  • Battery type: Polymer battery

LED Light Source

  • Light Source: LED
  • Stroboscopic Frequency: 2.25 Hz
  • Average service life: 100000 hours
  • Visible distance: 1500 Meters
  • Rated power: 1.44W
  • Continuous working time: ≥12 hours (Strong ), ≥30 hours (Strobe)

Parameters

  • Gear: 2-Step
  • Ambient Temperature (AT):-20℃~+55℃
  • Relative Humidity (RH):≤95(AT @ 25℃)
  • Dimensions: 185x113x70mm
  • Weight: 532g
  • Protection Level: IP65
  • Ex Markings: Pending



Operation Instructions

1.Each short press of the switch button, the brightness of the flashlight will cycle in the following sequence "working mode - strong light mode - flashing mode - off" .
2. Before use, charge the charger of this product. While charging, the indicator light is red. When fully charged, the indicator light turns green. The charger has a built-in charging protection device. If the charger is connected to the power supply and not charging, the indicator light will be shown as green.

The lamp is equipped with 4 power indication lights to help users identify remaining power at any time. The stages of remaining power are as follows: 100%~75% ●●●● 75% ~50% ●●● 50%~25% ●● 25%~10% ● When the power falls below 10%, one of the four indication lights will flash continuously for 3 times, indicating imminent power outage, the flashlight will become dimmer or unadjustable. At time of this, batteries should be replaced or recharged immediately.

Special Note

When the product is unused for more than 3 months, battery maintenance will be required. To do this, first discharge the battery completely, then recharge it to its full capacity.
